RBC Kits PF7U-3 Cutlass Jet EDF 90mm (CNC Wood Kit)

Oorspronkelijke prijs was: 149,17 €.Huidige prijs is: 97,99 €.

Artikelnummer: RBC-CUTLASS Categorieën: Airplanes, Jets EDF

100% kwaliteitsbelofte
Veilige transacties, tevreden klanten
7 dagen gratis retourneren
Meerdere betaalmethoden, veilig en betrouwbaar

Beschrijving
Beoordelingen (0)

More info

RBC Kits PF7U-3 Cutlass Jet EDF 90mm (CNC wood kit)

Turbines RC is pleased to introduce the new RBC range of high-quality all-wood kits to assemble yourself. All CTP and Balsa parts are CNC cut. This model, once mounted, remains in one piece for easy transport.

You need of cause to be capable of flying a fast jet, cause the Cutlass is ballistic.

You can fligh it 5s or 6s, it is superfast. Now we can fly with ease 5 minutes plus full speed.

RBC jets are made for standard combos (motor + EDF) available on our website.Don’t hesitate to contact-us for recommendations.

Technical specifications

All Formers And Ribs CNC Cut
Unique Tab Lock Design
One Piece Design

Features

Wing Area: 32 dm2
Wing Span; 940 mm
Flight Weight: Starts at 1700 grams
Wing Loading: 54gr dm2 to 75gr dm2
Functions: 3 Channel, Ailevons & Throttle (ailerons needs delta mix)
EDF: 90mm (not included)

Includes

PF7U-3 Cutlass Jet (to be assemble)
Full Size Rolled Cad Plans With All Parts Shown
Vacuformed Canopy, wheel Cover, nose cone
Paper Intake Tube, PVC Outlet Tube
Control Horns, Steering Cables
Now Included! Waterslide Decals
Illustrated instructions manual (downloadable hereunder)
All Mounting pictures by the hereunder link :
https://www.rbckitsinstructions.com/edf-jets/instructions-f7u-3-cutlass

Requires

Wemotec Midi fan or schubeler HDS51 or any other 90mm fan with motor
Any inexpensive 3 Channel Radio
Light weight receiver
Light weight servos: About 18 grams
Electric speed controller
Battery: 5 or 6s lipo 3200mah
Thick and Thin CA glue
Hardware like hinges steering wires etc
Bungee Launch req. The model needs a 10mmx7m bungee with 10kg of pulling power

Wing is build straightforward
Rudders also and are removable

Fuselage simple building, paper ducts added, only sheeting now

Ready for finishing

Ready to go

Bottom view

Data sheet

Type of kit:	Wood kit
Wingspan (mm):	940
Flying weight (gr)	starts at 1700 gr
CG (Center of Gravity)	Check manual
Servos	2 x 17 gr standard gear
EDF Diameter Class (mm):	90
Battery Cells:	5s – 18.5v, 6s – 22.2v
Surfaces	Elevons
Landing Gear	None – belly lander
Material	ABS, Balsa, Wood
Required Radio	3 channels minimum
