RBC Kits P-80 "Shooting Star" Jet EDF 70mm (Wood Kit CNC)

RBC Kits P-80 "Shooting Star" Jet EDF 70mm (Wood Kit CNC) - Afbeelding 2

RBC Kits P-80 "Shooting Star" Jet EDF 70mm (Wood Kit CNC) - Afbeelding 3

RBC Kits P-80 "Shooting Star" Jet EDF 70mm (Wood Kit CNC) - Afbeelding 4

RBC Kits P-80 "Shooting Star" Jet EDF 70mm (Wood Kit CNC) - Afbeelding 5

RBC Kits P-80 “Shooting Star” Jet EDF 70mm (Wood Kit CNC)

Oorspronkelijke prijs was: 82,50 €.Huidige prijs is: 57,75 €.

Artikelnummer: RBC-P80 Categorieën: Airplanes, Jets EDF

100% kwaliteitsbelofte
Veilige transacties, tevreden klanten
7 dagen gratis retourneren
Meerdere betaalmethoden, veilig en betrouwbaar

Beschrijving
Beoordelingen (0)

More info

Note: the visible tip tanks on the main picture are not included

RBC Kits P-80 Jet EDF 70mm (wood Kit CNC)

Turbines RC is pleased to introduce the new RBC range of high-quality all-wood kits to assemble yourself. All CTP and Balsa parts are CNC cut. This model, once mounted, remains in one piece for easy transport.

RBC jets are made for standard combos (motor + EDF) available on our website.

Technical specifications

All Formers And Ribs CNC Cut
Unique Tab Lock Design
One piece design

Features

Wing Area: 14dm2
Wing Loading: 64gr dm² to 75gr dm²
Wing Span: 1100mm
Length: 1000mm
Flight Weight: starts at 900grams
Functions: 3 Channel, Ailevons & Throttle (ailerons needs delta mix)
EDF: Mini Fan 70mm (not included)

Includes

P-80 “Shooting Star” wood kit (to be assemble)
Full Size Rolled Cad Plans With All Parts Shown
Vacuformed Canopy
Paper intake / outlet tube
Control horns, Steering cables
Instructions manual in English (downloadable hereunder)
All Mounting pictures by the hereunder link: click here

Requires

3 Channel Radio with delta mixer
Light weight Receiver
Light weight Servos: About 9gr
Motor HETrc 2W (3S)
ESC
EDF: Wemotec Mini fan 480 or HET 6904 any other 70mm fan with motor
Battery: 3S 3700mAh Li-Po
Thick and Thin CA glue
Bungee Launch req.: the model needs a 8mmx7.5m bungee with 8kg of pulling power

Data sheet

Type of kit:	Wood kit
Wingspan (mm):	1100
Length (mm):	1000
Flying weight (gr)	900
Wing Surface Area:	14 dm²
Wing Loading:	64gr to 75gr dm²
CG (Center of Gravity)	Check manual
Servos	9 gr
EDF Diameter Class (mm):	70
Battery Cells:	3s – 11.1v
Battery Capacity (mAh)	3700
Surfaces	Tailerons
Landing Gear	None – belly lander
Material	ABS, Balsa, Wood
Required Radio	3 channels minimum
