RBC Kits L-39 Albatros EDF 90mm (Wood Kit CNC)
Oorspronkelijke prijs was: 195,00 €.95,99 €Huidige prijs is: 95,99 €.
- 100% kwaliteitsbelofte
- Veilige transacties, tevreden klanten
- 7 dagen gratis retourneren
- Meerdere betaalmethoden, veilig en betrouwbaar
More info
RBC Kits L-39 Albatros Jet EDF 90mm (Wood Kit CNC)
Turbines RC is pleased to introduce the new RBC range of high-quality all-wood kits to assemble yourself. All CTP and Balsa parts are CNC cut. You can fligh it with a 8S Li-Po battery.
The L-39 Albatros is very easy to fly and lands slow as a trainer.
RBC jets are made for standard combos (motor + EDF) available on our website.
Nota: It is possible to install electric retracts.
Technical specifications
- All Formers And Ribs CNC Cut
- Unique Tab Lock Design
- Removable wings for easy transportation and storage
Features
- Wing Span: 1280mm
- Total lenght: 1525mm
- Flight Weight: starts at 3900grams
- Functions: 7 Channel, ailerons, elevator, flaps, throttle, retracts and nosewheel steering
- EDF: Midi Fan 90mm (not included)
Includes
- L-39 Albatros wood kit (to be assemble)
- Full Size Rolled Cad Plans With All Parts Shown
- Vacuformed Canopy, inlet lip
- Paper inlet/exhaust ducting
- All wood and sheeting
- List of required small parts
- No hardware in this kit
- Instructions manual in English (downloadable hereunder)
- All Mounting pictures by the hereunder link :
- https://www.rbckitsinstructions.com/edf-jets/instructions-l39-albatros
Requires
- 7 Channel Radio
- Light weight Receiver
- Light weight Servos: 7x13gr metal gear
- Wemotec Midi fan or Schubeler HDS51 or any other 90mm fan
- Motor HETrc EDF650-68-1500 8S
- ECS: 120A 8S
- Battery: 8S Li-Po 5000mAh
- Thick and Thin CA glue, 3/3
- Small parts, screws…
Rudder nice build up
Stabilizer also build up
Wing build up in 2 halves joined with spruce joiners ans some glass and epoxy
Fuselage all formers ply and hollow out to save weight
Intakes easy set up with hard paper and balsa sheet inlet
all sheeted nice
ready to paint
Canopy parts are also cnccut (included no pilots)
Data sheet
| Type of kit: | Wood kit |
| Wingspan (mm): | 1280 |
| Length (mm): | 1525 |
| Flying weight (gr) | 3900 |
| CG (Center of Gravity) | Check manual |
| Servos | 7x13gr metal gear |
| EDF Diameter Class (mm): | 90 |
| Battery Cells: | 8s – 29.6v |
| Battery Capacity (mAh) | 5.000 mAh |
| Surfaces | Ailerons, Elevator, Flaps |
| Landing Gear | Retractable |
| Material | ABS, Balsa, Wood |
| Required Radio | Minimum 7 channels |
