RBC Kits HE162 “Volksjager” EDF 90mm (Wood Kit CNC)
Oorspronkelijke prijs was: 174,17 €.98,99 €Huidige prijs is: 98,99 €.
- 100% kwaliteitsbelofte
- Veilige transacties, tevreden klanten
- 7 dagen gratis retourneren
- Meerdere betaalmethoden, veilig en betrouwbaar
More info
RBC Kits HE162 “Volksjager” Jet EDF 90mm (Wood Kit CNC)
Turbines RC is pleased to introduce the new RBC range of high-quality all-wood kits to assemble yourself. All CTP and Balsa parts are CNC cut.
RBCÂ jets are made for standard combos (motor + EDF) available on our website.
Nota: It is possible to install electric retracts.
Technical specifications
- All Formers And Ribs CNC Cut
- Unique Tab Lock Design
- 3D pdf on the CD with a lot of build pictures
Features
- Wing Area: 30dm2
- Wing Span: 1100mm
- Total lenght: 1500mm
- Flight Weight:Â starts at 3200grams
- Wing Loading: 110gr dm2 to 175gr dm2
- Functions: 6 Channel, ailerons, elevator, flaps, throttle, retracts and retracts steering
- EDF: Midi Fan 90mm (not included)
IncludesÂ
- HE162 Volksjager wood kit (to be assemble)
- Full Size Rolled Cad Plans With All Parts Shown
- Vacuformed Canopy, fairings, nose cone, intake
- Aluminium sheet for wheel doors etc. PVC Outlet Tube
- All wood and stringers
- No hardware in this kit
- Illustrated instructions manual (downloadable hereunder)
- All Mounting pictures by the hereunder link :
- https://www.rbckitsinstructions.com/edf-jets/instructions-he-162
Requires
- Wemotec Midi fan or Schubeler HDS51 or any other 90mm fan
- 6Â Channel Radio
- Light weight Receiver
- Light weight Servos: About 18gr
- ESC
- Motor
- Battery:Â 6S to 8Slipo
- Thick and Thin CA glue, uhu hart, white glue
Bones of the HE162, on the cd are 3d pdf for viewing the parts
Fuselage is build on a included building Jig, very handy, strip planking lots of work
Wing build easy. with flaps (you need them for a safe start)
Motor housing, formers and strip planking like fuselage
All prepared for retracts, details are on the drawing
Flaps can also be build in
Motor pod with unique closing system
Fan builds in easy
Battery acces through removable canopy, battery tray included in kit also
Data sheet
| Type of kit: | Wood kit |
| Wingspan (mm): | 1100 |
| Length (mm): | 1500 |
| Flying weight (gr) | 3200 |
| Wing Surface Area: | 30 dm² |
| Wing Loading: | 110gr to 175gr dm² |
| CG (Center of Gravity) | Check manual |
| Servos | 18gr |
| EDF Diameter Class (mm): | 90 |
| Battery Cells: | 6s – 22.2v, 7s – 21.77v, 8s – 29.6v |
| Surfaces | Ailerons, Elevator, Flaps |
| Landing Gear | (optional landing gear), (optional stearing gear is available) |
| Material | ABS, Balsa, Wood |
| Required Radio | 6 channels minimum |
