RBC Kits F9F-6 "Cougar" Jet EDF 90mm (Wood Kit CNC)

RBC Kits F9F-6 "Cougar" Jet EDF 90mm (Wood Kit CNC) - Afbeelding 2

RBC Kits F9F-6 "Cougar" Jet EDF 90mm (Wood Kit CNC) - Afbeelding 3

RBC Kits F9F-6 "Cougar" Jet EDF 90mm (Wood Kit CNC) - Afbeelding 4

RBC Kits F9F-6 "Cougar" Jet EDF 90mm (Wood Kit CNC) - Afbeelding 5

RBC Kits F9F-6 “Cougar” Jet EDF 90mm (Wood Kit CNC)

Oorspronkelijke prijs was: 149,17 €.Huidige prijs is: 99,99 €.

Artikelnummer: RBC-F9F-6 COUGAR Categorieën: Airplanes, Jets EDF

100% kwaliteitsbelofte
Veilige transacties, tevreden klanten
7 dagen gratis retourneren
Meerdere betaalmethoden, veilig en betrouwbaar

Beschrijving
Beoordelingen (0)

More info

RBC Kits F9F-6 Cougar Jet EDF 90mm (Wood Kit CNC)

Turbines RC is pleased to introduce the new RBC range of high-quality all-wood kits to assemble yourself. All CTP and Balsa parts are CNC cut. This model, once mounted, remains in one piece for easy transport.

RBC jets are made for standard combos (motor + EDF) available on our website.

Nota: It is possible to install electric retracts.

Technical specifications

All Formers And Ribs CNC Cut
Unique Tab Lock Design
One piece design

Features

Wing Area: 45dm2
Wing Span: 1030mm
Lenght: 1182mm
Flight Weight: starts at 2900grams
Wing Loading: 54gr dm² to 75gr dm²
Functions: 4 Channel, Ailerons, Elevator, Throttle & Retracts (non included)
EDF: Midi Fan 90mm (not included)

Includes

F9F-6 “Cougar wood kit (to be assemble)
Full Size Rolled Cad Plans With All Parts Shown
Vacuformed Canopy, fairings, nose cone
Paper Intake tube
PVC/Paper outlet tube
Illustrated instructions manual (downloadable hereunder)
All Mounting pictures by the hereunder link :
https://www.rbckitsinstructions.com/edf-jets/instructions-f9f-6-cougar

Requires

4 Channel Radio
Light weight Receiver
Servos: About 18gr
Motor: HETrc 600 Serie
EDF: Wemotec Midi fan or Schubeler EDF DS51 or any other 90mm fan with motor
ESC: 70Amp
Battery: 6S to 8S Li-Po
Thick and Thin CA glue
Bungee Launch (or retracts prepared)
Control Horns, Steering cables
There is no hardware in this kit

All fine cnccut formers from light ply and balsa

hard paper intace duct

strip planking with 2mm balsa

classic wing build

elevator servo in rudder

wing joined permanent to fuselage

Canopy from clear petg build onto frame , makes also the battery hatch

prepared for retracts air or electric

Data sheet

Type of kit:	Wood kit
Wingspan (mm):	1030
Length (mm):	1182
Flying weight (gr)	2900
Wing Surface Area:	45 dm²
Wing Loading:	54gr dm² à 75gr dm²
CG (Center of Gravity)	Check manual
Servos	18gr metal
EDF Diameter Class (mm):	90
Battery Cells:	6s – 22.2v, 8s – 29.6v
Surfaces	Ailerons, Elevator
Landing Gear	Retractable
Material	ABS, Balsa, Wood
Required Radio	4 channels minimum
