RBC Kits A4 Skyhawk Jet EDF 70mm (CNC Wood Kit)

RBC Kits A4 Skyhawk Jet EDF 70mm (CNC Wood Kit) - Afbeelding 2

RBC Kits A4 Skyhawk Jet EDF 70mm (CNC Wood Kit) - Afbeelding 3

RBC Kits A4 Skyhawk Jet EDF 70mm (CNC Wood Kit) - Afbeelding 4

RBC Kits A4 Skyhawk Jet EDF 70mm (CNC Wood Kit) - Afbeelding 5

RBC Kits A4 Skyhawk Jet EDF 70mm (CNC Wood Kit) - Afbeelding 6

RBC Kits A4 Skyhawk Jet EDF 70mm (CNC Wood Kit) - Afbeelding 7

RBC Kits A4 Skyhawk Jet EDF 70mm (CNC Wood Kit) - Afbeelding 8

RBC Kits A4 Skyhawk Jet EDF 70mm (CNC Wood Kit) - Afbeelding 9

RBC Kits A4 Skyhawk Jet EDF 70mm (CNC Wood Kit)

Oorspronkelijke prijs was: 86,67 €.Huidige prijs is: 60,67 €.

Artikelnummer: RBC-A4 Categorieën: Airplanes, Jets EDF

100% kwaliteitsbelofte
Veilige transacties, tevreden klanten
7 dagen gratis retourneren
Meerdere betaalmethoden, veilig en betrouwbaar

Beschrijving
Beoordelingen (0)

More info

RBC Kits CNC A4 Skyhawk Jet EDF 70mm (CNC wood Kit)

Turbines RC is pleased to introduce the new RBC range of high-quality all-wood kits to assemble yourself. All CTP and Balsa parts are CNC cut.

This model is fully modular allowing to later install / dismount the wings and tail by screws, thus facilitating access to the EDF and the battery.

The Douglas A-4 Skyhawk is a single seat subsonic carrier-capable attack aircraft developed for the United States Navy and United States Marine Corps in the early 1950s. The delta winged, single turbojet engined Skyhawk was designed and produced by Douglas Aircraft Company, and later by McDonnell Douglas.

RBC jets are made for standard combos (motor + EDF) available on our website.

Technical specifications

All formers and ribs CNC cut
Unique tab lock design
Motor/Battery compartment easy accesable

Features

Wingspan: 700mm
Length: 1060mm
Flying weight: starts at 1250g
Functions: Ailerons, throttle
EDF: 70mm (no included)

Includes

A4 Skyhawk Jet (to be assemble)
AUTOCAD plans with all parts shown
Vacuumformed canopy
PVC outlet tube (to roll)
Control horns, steering cables ball links
All Mounting pictures by the hereunder link :
https://www.rbckitsinstructions.com/edf-jets/instructions-a4

Requires

EDF 70mm type MiniFan Evo Wemotec + Motor HET 2W 4600Kv 3S or similar
ESC 60A to 80A
Lipo Battery 3 or 4S 3200mAh
2x Metal Servos 9g
Catapult system (8mmx7.5m bungee with 10Kg of pulling power)
Thick and thin Cyano glue
Cover (fiber, silk or Oracover according to your choice)
Recommended Radio and Receiver: 3 channel

When finished it’s time to set up the fan unit

with exhaust tube and speed controller.

Just slide it in. and take care for the wiring.

Ready to be mounted to fuselage.

Line up.

Screw tight the tail cone.

Receiver and battery setup.

The Skyhawk is a n excellent flyer but needs a bungee launch to get going,

In comparison with the Skyray it needs a bit more “twang” to launch it safely.

Then it has to pick up speed for a few meters , and then….

enjoy the jet feeling of the Skyhawk with loops and rolls.

With the Plettenberg 200-20-6 and 10 cells 1250mAh it fly’s for 3 minutes ok,

With a Kontronik Fun 480-33 and 12 cells 1250mAh it fly’s with great authority and speed.

The Skyhawk needs a 8mmx7,5mtr bungee with 8kg of pulling power.

Pictures from Max Zuijdendorps Skyhawk,
finished in oracover with self adhesive lettering

3 sheets of self adhesive lettering, the format is A4, the color is adapted to suit Oracover.

In the color of the Blue Angels, you only have to print and cut out the sheets yourself

Data sheet

Type of kit:	Wood kit
Wingspan (mm):	700
Length (mm):	1060
Flying weight (gr)	starts at 1250g
EDF Diameter Class (mm):	70
Material	ABS, Balsa, Wood
Required Radio	3 channels minimum
